| Place of Origin: | Jiangsu China |
|---|---|
| Brand Name: | AIPREL |
| Certification: | ISO |
| Model Number: | ACCESSEN |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Standard Carton |
| Delivery Time: | 1-2 weeks |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10,000 Units Per Month |
| Warranty: | 1 Year | Maximum Working Pressure: | 2.0 Mpa |
|---|---|---|---|
| Condition: | New | Application: | Heating Or Cooling,Heat Transfer,HVAC,Refrigeration Parts,Heater Parts |
| Gasket Material: | EPDM,HNBR,FKM,NBR EPDM FKM,FDA Stan | ||
| Highlight: | nbr gaskets,nbrp gasket |
||
Our Advantages
a. providing all kinds of material and type gaskets.
b. manufacturer of phe replacement plates and gaskets for GEA,Tranter,Sondex,Funke,Thermowave,APV.
c. not only producing conventional plates, but alsosemi-welded,free-flow plate.
d. designing and calculating new PHE according to technical specification provided by customers in different industry conditions.
e. high quality,reasonable price,fast delivery.
f. We are the source,keeping a large stock to ensure delivery.
g. ISO9001 & ISO14001
| Brand/Maker | Series |
| Accessen | AU03,AU05,AU08, |
| AU10L1,AU10L2, | |
| AU15L1,AU15L2,AU20,AU50,AU35,AU15,AU45,AU58,AU70,AU98, | |
| AN5,AN10,AN10M,AN10L2, | |
| AN15L1,AN15L2, | |
| AN20, | |
| AN25L1,AN25L2, | |
| AN30L1,AN30L2,AN30L3,AN30L4 | |
| AN35L1,AN35L2,AN35L3,AN35L4 | |
| AN40L1,AN40L2,AN40L3,AN40L4 | |
| AN45L1,AN45L2,AN45L3,AN45L4 | |
| AN50L1, | |
| AS6,AS10,AS20,AS25,AS30,AS40, | |
| AC15,AC25,AC35,AC45,AC50,AC65,AC70,AC98,AC150,AC180,AC190, | |
| AP5,AP8,AP20,AP25,AP35,AP075,AP98,AP120,AP165,AP210, |
Material and operating conditions of gasket:
| Material | Application | working temperature |
| NBR | Water, sea water, mineral oil, salt water | -15—130℃ |
| HNBR | High temperature mineral oil, high temperature water | 15—140℃ |
| EPDM | Water,Hot water, steam, acid, alkali | -25—150℃ |
| Viton／Fluorine Rubber | Strong acid, strong alkali, mineral oil, grease and fuel oil, etc | 5—200℃ |
| NEOPRENE | Acid, alkali, mineral oil, low molecular weight aliphatic hydrocarbon | 35—130℃ |
| Silicon Rubber | High temperature and some corrosive environments | 65—200℃ |
Introduction of plate heat exchanger manufacturer:
