| Place of Origin: | Jiangsu China |
|---|---|
| Brand Name: | AIPREL |
| Certification: | ISO |
| Model Number: | TRANTER |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | Standard Carton |
| Delivery Time: | 1-2 weeks |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10,000 Units Per Month |
| Warranty: | 1 Year | Maximum Working Pressure: | 2.0 Mpa |
|---|---|---|---|
| Structure: | Plate Heat Exchanger | Condition: | New |
| Application: | Heating Or Cooling,Heat Transfer,HVAC,Refrigeration Parts,Heater Parts | Gasket Material: | EPDM,HNBR,FKM,NBR EPDM FKM,FDA Stan |
| High Light: | phe plate,nbrp gasket |
||
Free flow plate heat exchanger, special free fluid design can effectively treat the fluid of higher viscosity,
larger particles, up to 11mm constant gap. It is no metal contact, can avoid dead spots,prevent blockage.
It has excellent heat transfer performance, easy disassembly, cleaning, maintenance, so it apply for sugar,
paper,fiber,Fermentation, crystallization, plastic,printing&dyeing and other process.
| Brand/Maker | Series |
| TRANTER | GCD006,GCD012,GLD013,GLP013,GCD018,GCP026,GCD030,GCP030, |
| GCP051,GCP054,GCD054,GCD055, | |
| SWEP | GCP060,GCD065,GCD018,GC8,GC12,GL13,GC26,GC30,GC42,GC51,GC60, |
| GL145,GL205,GL230,GL330, | |
| GX7,GX12,GX18,GX26,GX42,GX51,GX60,GX64,GX85,GX91, | |
| GX100,GX118,GX140,GX145,GXD012,GXP018, | |
| GX026,GXD026,GXP026,GXP037,GXD037, | |
| GX042,GXD042,GXP042,GX051,GXP051,GXD051, | |
| GXD060,GXD064,GXD085,GXD091,GXD100,GXP118,GXD140,GXD145, | |
| GFP030,GFP050,GF057,GFP057,GFP080,GFP097,GF097, | |
| GFP100,GFP180,GFP187,GF187, | |
| S3,S8,HX12,HXD012,HX25,HX50,HXD050,HX85,HXD085,HX180,HXD180,HXD145, | |
| GM56,GM59,GM138,GM257,GM276, | |
| TW5,TW10,TW18, | |
| UX01,UX05,UXP005,UXP010,UXP060,UX06T,UX10,UX20,UX40,UXP200,UXP400, | |
| UX80,UXP81,UX801,UXP900, | |
| G12,G28,G30,G48,G50,G55,G65,G66,G75,G78,G85, | |
| G95,G25,G52,G58,G102,G108,G153,G157,G158,G159, | |
| G214,G234,G254,G274,G322,G342,G52,G58,G65, | |
| GF138,GF257,GF276,GF59,MF138,MF257,MF276,MF56,MF59 |
Material and operating conditions of gasket:
| Material | Application | working temperature |
| NBR | Water, sea water, mineral oil, salt water | -15—130℃ |
| HNBR | High temperature mineral oil, high temperature water | 15—140℃ |
| EPDM | Water,Hot water, steam, acid, alkali | -25—150℃ |
| Viton／Fluorine Rubber | Strong acid, strong alkali, mineral oil, grease and fuel oil, etc | 5—200℃ |
| NEOPRENE | Acid, alkali, mineral oil, low molecular weight aliphatic hydrocarbon | 35—130℃ |
| Silicon Rubber | High temperature and some corrosive environments | 65—200℃ |
Introduction of plate heat exchanger manufacturer:
